Speed Reducer, C-Face, 56C, 100:1 MPN:E35MWNS, 100:1, 56C

Speed Reducer, Input Connection Type C-Face, Gear Type Worm, Output Shaft Type Keyed, Maximum Output Speed 17 RPM, Motor Frame Designation 56C, Worm Center Distance 3.5 in, Base to Center 4 in, Gear Ratio 100:1, Rotation CW/CCW, Maximum Input Horsepower 0.5 hp, Maximum Output Torque 1243 in-lb, Overhung Load Capacity 150 lb, Mounting Orientation Any Angle, Housing Material Cast Iron, Housing Material Finish Epoxy Coating System
