Indexable Profiling End Mill, M1200 Series, High Speed Steel, 4.50mm Depth of Cut
The Widia Indexable Profiling End Mill M1200 Series is a high-speed steel tool designed for efficient machining. Its 4.50mm depth of cut and 61.00mm maximum cutting diameter enable precise profiling and face milling applications. The tool's overall length of 40.00mm and coolant-fed design facilitate smooth operation and extended tool life. With its ANSI code M1200D050Z05HN09 and compatible hardware insert screw, this end mill is suitable for a range of industries, including aerospace, automotive, and general machining. Its compact size and ease of use make it an ideal choice for both new and experienced machinists.
Top product features:
- Indexable Profiling End Mill is designed for high-speed cutting applications
- Cutting Application is compatible with both side and face milling
- The tool features a coolant-fed design with a coolant through groove for improved cooling and chip evacuation
Top product applications:
- Side milling
- Face milling
- Cutting
Indexable Profiling End Mill, Max. Cutting Dia. 61.00mm, Depth of Cut 4.50mm, Overall Length 40.00mm, ANSI Code M1200D050Z05HN09, Compatible Hardware Insert Screw M4x0.7 x 10 T15, LHCS with Coolant Groove, Torx Driver, Coolant Fed Coolant Through, Cutting Application Side and Face Milling
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 67 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 9.84
- Package Width: 7.09
- Package Height: 3.15
- Package Weight: 0.72
- California Prop 65 Warning: WARNING: Cancer - www.P65Warnings.ca.gov
Product info last updated on February 3, 2026 5:59am UTC
Category: Cutting Tools
