Indexable Profiling End Mill, M200 Series, High Speed Steel, 3.00mm Depth of Cut MPN:4147572
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3801023
Indexable Profiling End Mill, M200 Series, High Speed Steel, 3.00mm Depth of Cut
The Widia M200 Series Indexable Profiling End Mill is a high-speed steel cutting tool designed for efficient 3D profiling, face milling, pocketing, and side/shoulder milling applications. Its ball nose design and square end capabilities make it suitable for a variety of cutting tasks. With a maximum cutting diameter of 63.00mm and a depth of cut of 3.00mm, this end mill delivers precise results. Its coolant-fed design ensures optimal performance and longevity. Ideal for industries such as aerospace, automotive, and medical, this tool reduces production time and increases productivity, making it a valuable addition to any machining operation.
Top product features:
- High Speed Steel construction for durability and resistance to wear
- Cutting Dia. of 63.00mm for efficient machining of large workpieces
- Coolant Fed design for effective heat management and reduced tool wear
Top product applications:
- 3D Profiling
- Face Milling
- Pocketing
Indexable Profiling End Mill, Max. Cutting Dia. 63.00mm, Depth of Cut 3.00mm, Shank Dia. 22.00mm, Overall Length 50.00mm, ANSI Code M200D63Z05RN12, Compatible Hardware Insert Screw M4x0.7 x 10 T15, M10 x 30mm Socket Head Cap Screw, Torx Wrench TX15, Coolant Fed Coolant Through, Cutting Application 3D Profiling, Face Milling, Pocketing, Side/Shoulder Milling: Ball Nose, Slotting: Square End
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 50 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 9.84
- Package Width: 7.09
- Package Height: 3.15
- Package Weight: 1.39
- California Prop 65 Warning: WARNING: Cancer - www.P65Warnings.ca.gov
Product info last updated on February 10, 2026 11:06pm UTC
Category: Cutting Tools
