Cooling Tower Motor, Three Phase, 20 HP, 1, 765 Nameplate RPM, 200V AC, 254/6T Frame MPN:02018ET3PCT256TF1-W2
Cooling Tower Motor, Three Phase, 20 HP, 1, 765 Nameplate RPM, 200V AC, 254/6T Frame
This 20 HP three-phase cooling tower motor is designed for heavy-duty applications in industrial settings, providing efficient and reliable operation. With a 1,765 RPM nameplate speed and 200V AC voltage, it can handle demanding cooling tower systems. The totally enclosed fan-cooled design ensures optimal performance and longevity, while the rigid base motor mounting type and all-angle motor mounting position provide flexibility and ease of installation. Suitable for use in a variety of industries, including manufacturing, power generation, and HVAC, this motor offers a high service factor and can operate in temperatures up to 40°C, making it an ideal choice for demanding cooling tower applications.
Top product features:
- Totally Enclosed Fan Cooled for improved reliability and reduced maintenance
- Three-Phase motor design for increased power and efficiency
- Ball Bearings for smooth and durable operation
Top product applications:
- Cooling towers for large commercial or industrial buildings
- Industrial air conditioning systems
- Large-scale water treatment facilities
Cooling Tower Motor, Three-Phase, Totally Enclosed Fan Cooled, 20 hp HP, 1,765 RPM Nameplate RPM, 254-6T Frame, CW/CCW Motor Shaft Rotation, 200V AC Voltage, 55.4 A Full Load Amps, Three Phase, 60 Hz Hz, Rigid Base Motor Mounting Type, Motor Mounting Position All Angle, Motor Bearings Ball, Motor Frame Material Cast Iron, None Motor Thermal Protection, 1.25 Motor Service Factor, Ambient Temperature 40 Degrees C, Shaft Dia. 1 5/8 in, Shaft Length 4 in, Length Less Shaft 20 15/16 in
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 29.10
- Package Width: 20.20
- Package Height: 15.80
- Package Weight: 270.00
Product info last updated on February 13, 2026 9:13pm UTC
Category: Motors
