Three-Phase General Purpose Motor, 3 HP, 182TC Frame, 230/460V AC Voltage, 3600 Nameplate RPM MPN:00336ET3E182TC-W22
Three-Phase General Purpose Motor, 3 HP, 182TC Frame, 230/460V AC Voltage, 3600 Nameplate RPM
This three-phase general purpose motor from Weg is designed for a wide range of applications, including industrial and commercial use. Its 3 HP capacity and 3600 nameplate RPM make it suitable for heavy-duty operations, while its totally enclosed fan cooled motor enclosure ensures efficient cooling and reduced maintenance. The motor's rigid base and C-face mounting type provide stability and easy installation. With a service factor of 1.25 and a nominal efficiency of 86.5%, this motor is ideal for continuous duty applications, including pumps, fans, and conveyor systems, where reliability and performance are critical.
Top product features:
- Totally Enclosed Fan Cooled Motor Enclosure Design
- Ball Motor Bearings
- CW/CCW Motor Shaft Rotation
Top product applications:
- Industrial machinery
- Pump systems
- Fans and blowers
General Purpose Motor, Three-Phase, Totally Enclosed Fan Cooled Motor Enclosure Design, 3 HP, Nameplate RPM 3515 rpm, Frame 182TC, Voltage 230/460V AC, 60 Hz Hz, Three Phase, Full Load Amps 7.26/3.63 A, Rigid Base, C-Face Motor Mounting Type, Motor Thermal Protection None, Ins. Class F, Motor Service Factor 1.25, Ball Motor Bearings, Motor Frame Material Cast Iron, Max. Ambient Temp. 40 Degrees C, CW/CCW Motor Shaft Rotation, Nominal Efficiency 86.5 Percent, Continuous Duty, 3001-3600
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 18.00
- Package Width: 14.80
- Package Height: 12.00
- Package Weight: 95.00
Product info last updated on January 29, 2026 11:52pm UTC
Category: Motors
