10" Flanged Cast Iron Silent Check Valve MPN:1810A-DSY
10" Flanged Cast Iron Silent Check Valve
VAL-MATIC 1810A-DSY is a 10 in flanged cast iron silent check valve for general purpose water service. Its inline, spring-assisted silent check valve design is intended for reverse-flow control applications and to address noise and flow reversal effects in piping systems. This valve is rated for horizontal or vertical installation and uses a flange x flange connection with Class 125 flanges.
Key Features:
- Valve type: Silent check valve with inline body design
- Size: 10 in nominal valve and pipe size
- Body material: Cast Iron ASTM A 126
- Connection: Flange x Flange, ANSI Flange Class 125
- Media: Water
- Cracking pressure: 0.5 psi
- Maximum pressure: 200 psig
- Operating temperature range: 33°F to 200°F
- Seat material: Bronze
- Seal material: Metal
- Spring material: 316 Stainless Steel
- Flow design: Single
- Flow rating: 1,450 gpm
- 2,500 gpm
- Mounting orientation: Horizontal, Vertical
- Overall length: 15.5 in
- Standards: ANSI 372, ASME B16.34, ISO 9001, MSS SP-126
- NSF certification: NSF 61
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 28.00
- Package Width: 31.00
- Package Height: 22.70
- Package Weight: 237.00
Product info last updated on June 4, 2026 10:53pm UTC
Category: Pipes, Valves and Fittings
