3-Phase Pump Motor, 5 HP, 184TP Frame, 230/460V AC Voltage, 1, 770 Nameplate RPM 23 in Overall Length MPN:HT5P2BLE
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G7733184
3-Phase Pump Motor, 5 HP, 184TP Frame, 230/460V AC Voltage, 1, 770 Nameplate RPM 23 in Overall Length
This 3-Phase Pump Motor from US Motors is designed for continuous duty cycles, making it ideal for applications requiring reliable and efficient operation. With a 5 HP rating and 184TP frame, it can handle demanding tasks in various industries. The motor's premium efficiency and inverter rating of 20:1 (VT) and 4:1 (CT) ensure optimal performance and energy savings. Suitable for use in pumps, this motor's totally enclosed fan-cooled design and maximum ambient temperature of 40°C make it a reliable choice for applications in hot environments, such as manufacturing, water treatment, and oil and gas facilities.
Top product features:
- 3-Phase operation allows for efficient power distribution and reduced energy consumption.
- Totally Enclosed Fan-Cooled design provides a safe and reliable operating environment.
- Inverter Rated with a 20:1 (VT) and 4:1 (CT) ratio enables flexible and efficient operation with inverters.
Top product applications:
- Pump
- Inverter
- Continuous Duty
Pump Motor, Body Dia. 12.9 in, Bolt Circle Dia. 9 1/8 in, Duty Cycle Continuous, Frame 184TP, Hz 60 Hz, Full Load Amps 13.5/6.8, HP 5, Ins. Class F, Inverter Rated Inverter Rated, Inverter Rating 20:1 (VT), 4:1 (CT), Length Less Shaft 23 in, Max. Ambient Temp. 40 Degrees C, Max. SF Amps 15.0/7.5, Motor Application Pump, Motor Design Three-Phase, Motor Efficiency Group Premium Efficient, Motor Enclosure Design Totally Enclosed Fan-Cooled
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 17.50
- Package Width: 21.50
- Package Height: 37.00
- Package Weight: 170.00
Product info last updated on February 5, 2026 3:34am UTC
Category: Motors
