3-Phase Vector Motor, 100 HP, 405 Frame, 230/460V AC Voltage, 1, 780 Nameplate RPM
This 100 HP 3-phase vector motor is designed for high-performance applications in industrial settings. With a wide speed range of 5,000:1 and a maximum operating frequency of 60 Hz, it provides efficient operation and reliability. The motor's rigid base mounting type and totally enclosed non-ventilated design ensure quiet and maintenance-free operation. Ideal for use in applications such as conveyor systems, pumps, and fans, this motor offers a high torque output of 241 ft-lb and a maximum speed of 1,780 RPM. Its continuous duty cycle and high ambient temperature rating make it suitable for demanding industrial environments.
Top product features:
- Three-phase design for efficient energy usage
- Totally enclosed non-ventilated enclosure for safe operation in harsh environments
- Speed range of 5,000:1 for precise control over motor speed
Top product applications:
- Pumps and Pumping Systems
- Conveyor Systems
- Machine Tool and Fabrication Equipment
Vector Motor, Three Phase, Motor Design Three-Phase, 100 HP, Nameplate RPM 1,780, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 225.0/113.0 A, 405 Frame, Torque 241 ft-lb, Max. Speed 1,780 RPM, Speed Range 5,000:1, 60 Hz Hz, Max. Operating Frequency 60 Hz, Motor Service Factor 1, Motor Thermal Protection T-Stat, Ins. Class H, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, Motor Enclosure Design Totally Enclosed Non-Ventilated, Motor Mounting Type Rigid Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 40 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.50
- Package Width: 12.50
- Package Height: 19.50
- Package Weight: 1410.00
