Split-Phase General Purpose Motor, 1/2 hp HP, 115V AC Voltage, 56 Frame, 1, 725 RPM Nameplate RPM MPN:3306
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G4403806
Split-Phase General Purpose Motor, 1/2 hp HP, 115V AC Voltage, 56 Frame, 1, 725 RPM Nameplate RPM
This 1/2 hp split-phase general purpose motor is designed for a wide range of applications, including industrial and commercial use. With a nameplate RPM of 1,725, it provides reliable and efficient operation in various settings. Its compact 56 frame design and open drip proof enclosure make it easy to install and maintain. Suitable for continuous duty cycles, this motor is ideal for use in facilities with 115V AC voltage. Its rugged construction and durable design ensure long-lasting performance and minimize downtime, making it a reliable choice for applications such as conveyor systems, pumps, and fans.
Top product features:
- Operates at 1,725 RPM
- Has a Split-Phase motor design
- Is an Open Drip Proof motor enclosure design
Top product applications:
- Pumps and fans in residential and commercial settings
- Conveyor systems and other industrial equipment in manufacturing facilities
- Water treatment plants and other applications requiring continuous operation
General Purpose Motor, Single Phase, Motor Design Split-Phase, 1/2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 2, Voltage 115V AC, Full Load Amps 9.2/5.2 A, 56 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 18.50
- Package Width: 10.50
- Package Height: 10.88
- Package Weight: 26.00
