Motor, 145TC, Rigid Base MPN:HD1P3EC
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G1942082
Motor, 145TC, Rigid Base
The GP Motor from US Motors is a reliable and efficient solution for a wide range of industrial applications. This 1 HP, three-phase motor features a totally enclosed fan-cooled design and a cast iron frame for durability and long lifespan. With a nameplate RPM of 1,165 and a maximum ambient temperature of 40 degrees C, this motor is ideal for use in high-temperature environments. Its high efficiency and low amp draw make it a cost-effective choice for applications such as pumps, conveyors, and fans, while its CSA certification and UL recognition ensure compliance with industry standards.
Top product features:
- Totally Enclosed Fan Cooled Motor Enclosure Design
- Three-Phase Operation
- Ball Motor Bearings
Top product applications:
- Industrial conveyor systems
- Pumps and compressors
- Textile machinery
General Purpose Motor, Three-Phase, Totally Enclosed Fan Cooled Motor Enclosure Design, 1 HP, Nameplate RPM 1,165, Frame 145TC, Voltage 230/460V AC, 60/50 Hz Hz, Three Phase, Full Load Amps 3.7/1.8 A, Rigid Base Motor Mounting Type, Motor Thermal Protection None, Ins. Class F, Motor Service Factor 1.15, Ball Motor Bearings, Motor Frame Material Cast Iron, Max. Ambient Temp. 40 Degrees C, CW/CCW Motor Shaft Rotation, Nominal Efficiency 82.5 Percent, 1,101-1,200, CSA Certified, UL Recognized
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.50
- Package Width: 12.50
- Package Height: 9.12
- Package Weight: 70.00
Product info last updated on February 13, 2026 11:42pm UTC
Category: Motors
