3-Phase Belt Drive Motor, 2 HP, 56H Frame, 208-230/460V AC Voltage, 1, 725 Nameplate RPM MPN:8493P
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0919823
3-Phase Belt Drive Motor, 2 HP, 56H Frame, 208-230/460V AC Voltage, 1, 725 Nameplate RPM
This 3-Phase Belt Drive Motor is a reliable and efficient solution for various applications, including fans and blowers. With a 2 HP output and 1,725 RPM, it provides consistent performance in demanding environments. The motor's 56H frame and open drip-proof design ensure durability and easy maintenance. Suitable for 208-230/460V AC voltage, it can be used in a range of settings, including commercial and industrial facilities. Its compact size and lightweight design make it easy to install and integrate into existing systems, providing a cost-effective and reliable solution for fans and blowers.
Top product features:
- Three-phase design for efficient power distribution
- Keyed shaft for secure attachment and alignment of accessories
- Open drip-proof enclosure for protection against dust and water in harsh environments
Top product applications:
- Air Conditioning and Refrigeration
- Industrial Fan and Blower Systems
- Material Handling and Conveyors
Fan and Blower Motor, Three Phase, Motor Design Three-Phase, 2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 208-230/460V AC, 6.1-6.3/3.1 A Full Load Amps, 56H Frame, 60 Hz Hz, Usable @ 208V Usable at 208V, Motor Service Factor 1.15, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Cradle Base, Shaft Length 1 31/32 in, Shaft Dia. 5/8 in
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.50
- Package Width: 8.40
- Package Height: 11.10
- Package Weight: 40.15
Product info last updated on February 3, 2026 4:25pm UTC
Category: Motors
