Farm Duty Motor, 3-Phase, 1 HP, 230V AC, 850 Nameplate RPM, 56YZ Frame MPN:FD1AA4KCR
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0919421
Farm Duty Motor, 3-Phase, 1 HP, 230V AC, 850 Nameplate RPM, 56YZ Frame
This 1 HP, 3-phase motor is designed for farm duty applications, providing reliable performance in harsh environments. With a nameplate RPM of 850 and a 56YZ frame, it can handle heavy loads and withstand extreme temperatures. Suitable for use at 230V or 208V, it offers flexibility in installation. Its totally enclosed air-over design ensures protection from dust and moisture, while its continuous duty cycle enables long-term operation. Ideal for use in agricultural equipment, pumps, and other machinery, this motor provides a reliable and efficient power solution for demanding applications.
Top product features:
- Operates at 850 nameplate RPM for efficient power delivery
- Has a totally enclosed air-over design for protection from dust and moisture
- Features a continuous duty cycle for reliable operation in demanding applications
Top product applications:
- Farm irrigation systems
- Pumping water for livestock
- Powering agricultural equipment
Farm Duty Motor, Three Phase, Motor Design Three-Phase, 1 hp HP, Nameplate RPM 850 RPM, No. of Speeds 1, Voltage 230V AC, Full Load Amps 5.8 A, 56YZ Frame, Usable @ 208V Usable at 208V, 60 Hz Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Flange, Motor Frame Material Steel, Shaft Dia. 5/8 in, Shaft Length 2 1/2 in
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 18.50
- Package Width: 10.50
- Package Height: 10.88
- Package Weight: 32.00
Product info last updated on February 1, 2026 4:16am UTC
Category: Motors
