Farm Duty Motor, 3-Phase, 1 HP, 440-460V, 850 Nameplate RPM, 56YZ Frame MPN:8101
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0919315
Farm Duty Motor, 3-Phase, 1 HP, 440-460V, 850 Nameplate RPM, 56YZ Frame
This 1 HP, 3-phase farm duty motor from US Motors is designed for heavy-duty applications in agricultural settings. With a nameplate RPM of 850 and a 56YZ frame, it provides reliable and efficient performance. Suitable for use in environments with high ambient temperatures up to 40°C, it features automatic thermal protection and a totally enclosed air-over design for added durability. Ideal for applications such as irrigation pumps, feed grinders, and grain dryers, this motor offers continuous duty cycle operation and can be used at 440-460V AC. Its compact design and flange mounting make it easy to integrate into existing systems.
Top product features:
- Three-phase operation
- Totally enclosed air-over design
- Continuous duty cycle
Top product applications:
- Pump and irrigation systems
- Well and borehole pumping
- Farm and ranch irrigation systems
Farm Duty Motor, Three Phase, Motor Design Three-Phase, 1 hp HP, Nameplate RPM 850 RPM, No. of Speeds 1, Voltage 440-460V AC, Full Load Amps 2.0 A, 56YZ Frame, Usable @ 208V Not Usable at 208V, 60 Hz Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Flange, Shaft Dia. 3/4 in, Shaft Length 2 13/16 in
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 18.50
- Package Width: 10.50
- Package Height: 10.88
- Package Weight: 32.00
Product info last updated on January 14, 2026 11:00pm UTC
Category: Motors
