Farm Duty Motor, 3-Phase, 1 HP, 208-230/460V AC, 1, 725 Nameplate RPM, 56H Frame MPN:FD1EA2D
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0407931
Farm Duty Motor, 3-Phase, 1 HP, 208-230/460V AC, 1, 725 Nameplate RPM, 56H Frame
This 1 HP, 3-phase farm duty motor is designed for heavy-duty applications in agricultural settings. With a nameplate RPM of 1,725 and a 56H frame, it provides reliable performance in demanding conditions. Suitable for use at 208V, 60/50 Hz, it offers a service factor of 1.15 and automatic thermal protection. Its totally enclosed air-over design and rigid base mounting ensure durability and ease of installation. Ideal for irrigation systems, grain handling equipment, and other high-load agricultural machinery, this motor provides continuous duty operation in temperatures up to 40°C. Its compact size and robust construction make it a reliable choice for farm and ranch applications.
Top product features:
- Three-phase operation
- Totally enclosed air-over motor design
- Continuous duty cycle operation
Top product applications:
- Pump and irrigation systems for agricultural use
- Industrial equipment such as conveyors and pumps
- General purpose machinery for farms and ranches
Farm Duty Motor, Three Phase, Motor Design Three-Phase, 1 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 208-230/460V AC, Full Load Amps 3.1/1.5 A, 56H Frame, Usable @ 208V Usable at 208V, 60/50 Hz Hz, Motor Service Factor 1.15, Motor Thermal Protection Auto, Ins. Class F, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Rigid Base, Motor Frame Material Steel, Shaft Dia. 5/8 in
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.32
- Package Width: 10.50
- Package Height: 10.88
- Package Weight: 26.00
Product info last updated on February 5, 2026 3:35pm UTC
Category: Motors
