3-Phase Vector Motor, 3/4 HP, 56 Frame, 208-230/460V AC Voltage, 1, 140 Nameplate RPM MPN:UN34V2AC
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0404212
3-Phase Vector Motor, 3/4 HP, 56 Frame, 208-230/460V AC Voltage, 1, 140 Nameplate RPM
This 3-Phase Vector Motor from US Motors is a high-performance solution for various industrial applications. With a 3/4 HP rating and 1,140 nameplate RPM, it provides efficient and reliable operation. Suitable for use in 208-230/460V AC voltage environments, this motor boasts a speed range of 20:01 and a maximum speed of 1,725 RPM. Its compact 56 frame design and totally enclosed non-ventilated enclosure make it ideal for applications requiring high torque and durability. Perfect for use in manufacturing, material handling, and other industrial settings, this motor delivers consistent performance and long-lasting operation.
Top product features:
- Three-phase operation enables efficient power distribution and motor performance.
- Totally enclosed non-ventilated design protects the motor from environmental debris and moisture.
- Nameplate RPM of 1,140 provides a high-speed operation suitable for demanding applications.
Top product applications:
- Pump applications, such as water or chemical pumps
- Conveyor systems, including belt and roller conveyors
- Fans and blowers, including industrial and commercial ventilation systems
Vector Motor, Three Phase, Motor Design Three-Phase, 3/4 HP, Nameplate RPM 1,140, No. of Speeds 1, Voltage 208-230/460V AC, Full Load Amps 2.8-2.7/1.3 A, 56 Frame, Torque 174.5 ft-lb, Max. Speed 1,725 RPM, Speed Range 20:01, Usable @ 208V Usable at 208V, 60 Hz Hz, Max. Operating Frequency 60 Hz, Motor Service Factor 1.15, Motor Thermal Protection T-Stat, Ins. Class F, Max. Ambient Temp. 104 Degrees F, NEMA Design B, Motor Enclosure Design Totally Enclosed Non-Ventilated
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.32
- Package Width: 8.25
- Package Height: 11.00
- Package Weight: 26.00
Product info last updated on February 23, 2026 9:42pm UTC
Category: Motors
