3-Phase Motor, 3 HP, 182 Frame, 575V AC Voltage, 1, 765 Nameplate RPM 15 1/2 in Overall Length MPN:CW3V2G2
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0396792
3-Phase Motor, 3 HP, 182 Frame, 575V AC Voltage, 1, 765 Nameplate RPM 15 1/2 in Overall Length
This 3-phase motor from US Motors is a reliable and efficient solution for cooling tower applications. With a 3 HP rating and 1,765 RPM nameplate speed, it provides the necessary power and speed for optimal performance. Its totally enclosed fan-cooled design ensures reliable operation in harsh environments, while its rigid base motor mounting type provides stability and support. Suitable for horizontal mounting, this motor is ideal for use in industrial settings, including power generation, oil and gas, and water treatment facilities, where its high efficiency and robust design can help reduce maintenance and energy costs.
Top product features:
- Totally Enclosed Fan Cooled design for efficient heat dissipation
- Three-phase, 3 HP motor operation for high power output
- CW/CCW motor shaft rotation for flexible installation options
Top product applications:
- Cooling tower
- Industrial air conditioning systems
- Large HVAC systems
Cooling Tower Motor, Three-Phase, Totally Enclosed Fan Cooled, 3 hp HP, 1,765 RPM Nameplate RPM, 182T Frame, CW/CCW Motor Shaft Rotation, 575V AC Voltage, 3.2 A Full Load Amps, Three Phase, 60 Hz Hz, Rigid Base Motor Mounting Type, Motor Mounting Position Horizontal, None Motor Thermal Protection, 1.15 Motor Service Factor, Ambient Temperature 40 Degrees C, Shaft Dia. 1 1/8 in, Shaft Length 2 1/2 in, Length Less Shaft 13 in, Overall Length 15 1/2 in, Ins. Class F, Nominal Efficiency 89.5 Percent
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 40 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 23.00
- Package Width: 14.50
- Package Height: 15.00
- Package Weight: 100.00
Product info last updated on March 18, 2026 9:19am UTC
Category: Motors
