Capacitor-Start General Purpose Motor, 3/4 hp HP, 56C Frame, 100-120V AC Voltage MPN:T34C2ZCR
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0201235
Capacitor-Start General Purpose Motor, 3/4 hp HP, 56C Frame, 100-120V AC Voltage
This 3/4 hp capacitor-start general purpose motor from US Motors is designed for a wide range of applications, including residential and commercial use. With a 1,725 RPM nameplate speed, it provides efficient and reliable operation in single-phase systems. The motor's totally enclosed fan-cooled design and Class F insulation ensure long-lasting performance in harsh environments. Suitable for continuous duty cycles, it's an ideal choice for applications such as HVAC systems, water pumps, and conveyor belts. Its compact 56C frame and 100-120V AC voltage range make it a versatile solution for various industries and settings.
Top product features:
- Totally Enclosed Fan Cooled design for improved motor durability and reduced maintenance
- Single Phase, Capacitor-Start motor design for efficient operation and reliable starting
- Continuous Duty Cycle capability for uninterrupted operation in demanding applications
Top product applications:
- Pumps and water treatment systems
- Fans and blowers
- Conveyors and material handling equipment
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 3/4 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 100-120V AC, Full Load Amps 9.2-8.4/4.6-4.2 A, 56C Frame, Usable @ 208V Usable at 208V, Usable @ 200V Usable at 200V, Hz 60/50 Hz, Motor Service Factor 1.25, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class F, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 15 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 18.50
- Package Width: 12.00
- Package Height: 12.00
- Package Weight: 23.00
Product info last updated on February 23, 2026 8:32pm UTC
Category: Motors
