Sprocket, Plain, 80 Chain Size, 1 Bore Dia., 24 # of Teeth MPN:80B24
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3225887
Sprocket, Plain, 80 Chain Size, 1 Bore Dia., 24 # of Teeth
This 80 chain size sprocket from Tsubaki is a high-quality, steel component designed for heavy-duty use. With 24 teeth and a 1-inch bore diameter, it provides reliable power transmission in a variety of applications, including industrial machinery and material handling systems. The sprocket's one-side hub design and black oxide finish ensure durability and resistance to wear and tear. Its keyway and set screws provide additional stability and ease of installation. Perfect for use in manufacturing, construction, and other industries where power transmission is critical, this sprocket delivers consistent performance and long-lasting reliability.
Top product features:
- One side hub type design allows for easy installation and removal of the sprocket.
- The sprocket includes set screws for secure attachment to a shaft.
- The keyway design enables the sprocket to be securely fastened to a shaft using a key.
Top product applications:
- Power Generation
- Conveyor Systems
- Industrial Automation
Sprocket, Bore Diameter 1 in, For Chain Pitch 1 in, For Number of Strands Single, Hub Type One Side, Material Steel, Maximum Bore Diameter 2 3/4 in, Number of Teeth 24, Outside Diameter 8.2 in, Pitch Diameter 7.661 in, Bore Type Plain, Chain Number 80, Finish Black Oxide, For Pitch Type Single Pitch, Hub Diameter 4 1/4 in, Hub Projection 1.175 in, Includes Set Screws, Keyway Yes, Keyway Depth 1/8 in, Keyway Width 1/4 in, Length through Bore 1 7/8 in, Material Grade 1045
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 8.90
- Package Width: 9.00
- Package Height: 2.20
- Package Weight: 12.60
Product info last updated on February 5, 2026 3:04pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
