Single Strand Sprocket, Plain, 40 Chain Size, 5/8 Bore Dia., 60 # of Teeth MPN:40B60SS
Single Strand Sprocket, Plain, 40 Chain Size, 5/8 Bore Dia., 60 # of Teeth
This single strand sprocket is designed for use with chain size 40, featuring a 5/8 inch bore diameter and 60 teeth. Constructed from high-quality stainless steel, it offers excellent durability and resistance to corrosion. The sprocket's one-side hub type and keyway design provide a secure and efficient connection to your system. Ideal for applications in industries such as manufacturing, material handling, and packaging, this sprocket is suitable for use in a variety of environments. Its compact size and lightweight design make it easy to integrate into your existing systems, minimizing downtime and maximizing productivity.
Top product features:
- Single Strand Sprocket is made of stainless steel for durability and resistance to corrosion.
- The sprocket features a keyway for secure key installation, allowing for precise control and alignment.
- The sprocket includes set screws for easy and secure attachment to shafts.
Top product applications:
- Conveyor systems
- Material handling equipment
- Power transmission systems
Single Strand Sprocket, Bore Diameter 3/4 in, For Chain Pitch 1/2 in, For Number of Strands Single, Hub Type One Side, Material Stainless Steel, Maximum Bore Diameter 2 3/8 in, Number of Teeth 60, Outside Diameter 9.84 in, Pitch Diameter 9.554 in, Bore Type Plain, Chain Number 40, For Pitch Type Single Pitch, Hub Diameter 3 1/2 in, Hub Projection 0.716 in, Includes Set Screws, Keyway Yes, Keyway Depth 3/32 in, Keyway Width 3/16 in, Length through Bore 1 in, Material Grade 304
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.50
- Package Width: 12.50
- Package Height: 4.00
- Package Weight: 7.94
Product info last updated on February 5, 2026 12:12pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
