Sprocket, 3/4" Bore Dia., 16 Teeth MPN:2062B16
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G005748003
Sprocket, 3/4" Bore Dia., 16 Teeth
This 3/4in bore diameter sprocket from Tsubaki features 16 teeth and is designed for use with a 1 1/2in chain pitch and single strand configuration. The steel construction provides durability and resistance to wear, while the black oxide finish enhances corrosion protection. Suitable for applications in temperatures up to 400°F, this sprocket is ideal for use in industrial settings, such as manufacturing and material handling systems. Its compact size and lightweight design make it easy to integrate into existing systems, offering improved efficiency and reduced maintenance requirements.
Top product features:
- The sprocket has 16 teeth, suitable for applications requiring moderate gear reduction.
- The sprocket is designed with a one-side hub type, allowing for efficient installation and removal.
- The sprocket has a black oxide finish, providing corrosion resistance and durability in harsh environments.
Top product applications:
- Pulleys and conveyors
- Chain drives and power transmission systems
- Automotive and industrial machinery
Sprocket, Bore Diameter 3/4 in, For Chain Pitch 1 1/2 in, For Number of Strands Single, Hub Type One Side, Material Steel, Maximum Bore Diameter 2 3/4 in, Number of Teeth 16, Outside Diameter 8.44 in, Pitch Diameter 7.689 in, Bore Type Plain, Chain Number C2062, Finish Black Oxide, For Pitch Type Double Pitch, Hub Diameter 4 in, Hub Projection 0.791 in, Keyway No, Length through Bore 1 1/4 in, Material Grade Type B, Maximum Operating Temperature 400 Degrees F
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 3 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 10.00
- Package Width: 10.00
- Package Height: 2.50
- Package Weight: 8.18
Product info last updated on January 17, 2026 1:02pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
