Spherical Plain, 70mm Bore, 160mm OD MPN:GX 70F
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G2080709
Spherical Plain, 70mm Bore, 160mm OD
This 70mm spherical plain bearing from Tritan offers high-performance capabilities in a compact design. Suitable for radial loads, it provides a dynamic load capacity of 1,590 kN, making it ideal for heavy-duty applications. The PTFE liner and alloy steel construction ensure smooth operation and durability. The bearing can withstand temperatures from -50°F to 300°F and is lubricated with MoS2. Its compact size and high load capacity make it suitable for use in industrial machinery, automotive systems, and aerospace applications, where precision and reliability are critical. It is also an excellent choice for applications where space is limited.
Top product features:
- Spherical Plain Bearing supports radial loads in a single direction.
- PTFE liner material provides low-friction movement.
- Chrome plating on the bearing surface reduces wear and tear.
Top product applications:
- Automotive Suspension Systems
- Robotics and Automation Equipment
- Heavy-Duty Industrial Equipment
Spherical Plain Bearing, Liner Material PTFE, Bore Diameter 70 mm, Ball Diameter 176 mm, Outer Ring Width 36.5 mm, Outside Diameter 160 mm, Outer Ring Material Alloy Steel, Ball Material Alloy Steel, Closure Open, Dynamic Radial Load Capacity 1,590 kN, Finish Chrome Plated, Flat Diameter 70 mm, Inner Ring Width 42 mm, Load Direction Radial, Thrust Single Direction, Lubricant Material MoS2, Maximum Temperature 300 Degrees F, Minimum Temperature -50 Degrees F, Overall Width 50 mm
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.30
- Package Width: 6.30
- Package Height: 1.97
- Package Weight: 12.05
Product info last updated on February 2, 2026 11:19pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
