Piston Air Compressor, 3/4HP, 115/230V, 1Ph MPN:270080
Piston Air Compressor, 3/4HP, 115/230V, 1Ph
The Thomas 270080 is an oil-lubricated, twin-cylinder piston air compressor with an articulated-piston design. It operates on 115/230V AC single-phase power at 60 Hz at a rated 3/4 hp output, in a tankless configuration. It provides a free-air delivery ranging from 2.25 CFM at 100 psi up to 2.4 CFM at 0 psi, and a maximum continuous pressure of 175 psi. It is rated at a maximum speed of 1,725 RPM, a full-load current of 10.6/5.3 A, and a measured sound level of 80 dBA. The operating temperature range is 32-104°F. Construction includes a cast iron cylinder, a capacitor-start motor, and stainless steel valves. The motor is totally enclosed. Air connections are 1/4 in NPT inlet and outlet. Overall dimensions are 15.5 x 12 x 7 in (L x W x H). It ships without a power cord. Country of origin: United States.
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 19.50
- Package Width: 16.60
- Package Height: 11.60
- Package Weight: 44.25
Product info last updated on March 22, 2026 1:20pm UTC
Category: Compressors, Air Tanks and Pneumatic Parts
