Inductive, Rectangular Proximity Sensor, PBT, Bare Wire, 4 Wires, Unshielded MPN:XS8C4A4PCN12
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G4988471
Inductive, Rectangular Proximity Sensor, PBT, Bare Wire, 4 Wires, Unshielded
This Inductive Rectangular Proximity Sensor is a reliable and efficient solution for detecting objects in various industrial settings. With a wide operating frequency of 200 Hz and a maximum detecting distance of 40 mm, it provides accurate and consistent results. The sensor's 4-wire PNP output circuit and screw clamp terminal ensure easy integration and connectivity. Suitable for use in harsh environments, it boasts an IP65, IP67, and IP69K rating, making it ideal for applications in food processing, pharmaceutical, and chemical industries. Its compact design and high current load capacity make it a versatile addition to any automation system.
Top product features:
- Inductive technology allows for reliable detection of metal objects
- Detects objects up to 40 mm away
- 4-wire PNP output circuit provides flexible connectivity options
Top product applications:
- Industrial Automation
- Automotive Assembly Lines
- Material Handling Systems
Inductive Rectangular Proximity Sensor, Inductive, Proximity Sensor Power Requirement 12 to 48V DC, Unshielded, Proximity Sensor Operating Frequency 200 Hz, Proximity Sensor Output Circuit Type 4 Wire PNP, Max. Detecting Distance 40 mm, Proximity Sensor Electrical Connection Screw Clamp Terminal, Output Mode NO/NC, IP Rating IP65, IP67, IP69K, Case Material Plastic, Length 117 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 200mA
Additional Information
- Country of Origin: FR
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.77
- Package Width: 5.70
- Package Height: 1.77
- Package Weight: 0.55
Product info last updated on February 18, 2026 12:29am UTC
Category: Industrial Electrical Controls and Automation
