Inductive, Rectangular Proximity Sensor, PBT, 1/2 in Connector, 2 Wires, Shielded MPN:XS8C2A1MAU20
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G4589706
Inductive, Rectangular Proximity Sensor, PBT, 1/2 in Connector, 2 Wires, Shielded
This inductive proximity sensor is designed for detecting metal objects in industrial settings. Its rectangular shape and compact size make it ideal for use in tight spaces. The sensor operates at a wide frequency range of 25 Hz AC/50 Hz DC, allowing it to detect objects with varying sizes and materials. With a maximum detecting distance of 20 mm, it provides accurate detection and reliable operation. Suitable for use in harsh environments, the sensor features an IP69K rating and operates within a wide temperature range. It's perfect for applications in manufacturing, material handling, and food processing.
Top product features:
- Inductive sensing technology allows for detection of objects within a 20 mm distance.
- The sensor operates within a wide frequency range of 25 Hz AC/50 Hz DC.
- The shielded design provides immunity to electrical noise and interference.
Top product applications:
- Automotive Body and Paint Shops
- Industrial Automation Systems
- Medical Device Manufacturing
Inductive Rectangular Proximity Sensor, Inductive, Proximity Sensor Power Requirement 24 to 240V AC/DC, Shielded, Proximity Sensor Operating Frequency 25 Hz AC/50 Hz DC, Proximity Sensor Output Circuit Type 2 Wire, Max. Detecting Distance 20 mm, Proximity Sensor Electrical Connection 3 Pin 1/2-20 UNF Male Connector, Output Mode NO, IP Rating IP65, IP67, IP69K, Case Material Plastic, Length 40 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 200mA
Additional Information
- Country of Origin: ID
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.40
- Package Width: 1.80
- Package Height: 1.50
- Package Weight: 0.29
Product info last updated on February 4, 2026 6:00pm UTC
Category: Industrial Electrical Controls and Automation
