Inductive, Rectangular Proximity Sensor, PBT, 1/2 in Connector, 2 Wires, Shielded MPN:XS7C2A1MAU20
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G4563885
Inductive, Rectangular Proximity Sensor, PBT, 1/2 in Connector, 2 Wires, Shielded
This inductive proximity sensor is a reliable and versatile solution for detecting objects within a 15mm range. Suitable for use in various applications, including industrial automation, manufacturing, and quality control, it can be powered by 24-240V AC/DC and operates at frequencies of 25Hz AC/50Hz DC. The sensor's shielded design and IP65, IP67, and IP69K ratings ensure durability in harsh environments. Its compact 40mm length and 1/2-20 UNF male connector make it easy to integrate into existing systems. With a maximum current load of 200mA, this sensor provides a robust and efficient solution for proximity detection.
Top product features:
- Inductive sensing technology allows the sensor to detect objects without physical contact.
- The sensor is shielded to reduce electromagnetic interference and improve reliability.
- The sensor has a maximum detecting distance of 15 mm, allowing it to detect objects at a close range.
Top product applications:
- Machine Guarding
- Automated Warehouse Management
- High-Speed Packaging Machines
Inductive Rectangular Proximity Sensor, Inductive, Proximity Sensor Power Requirement 24 to 240V AC/DC, Shielded, Proximity Sensor Operating Frequency 25 Hz AC/50 Hz DC, Proximity Sensor Output Circuit Type 2 Wire, Max. Detecting Distance 15 mm, Proximity Sensor Electrical Connection 3 Pin 1/2-20 UNF Male Connector, Output Mode NO, IP Rating IP65, IP67, IP69K, Case Material Plastic, Length 40 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 200mA
Additional Information
- Country of Origin: ID
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.40
- Package Width: 1.70
- Package Height: 1.80
- Package Weight: 0.30
Product info last updated on February 8, 2026 2:44pm UTC
Category: Industrial Electrical Controls and Automation
