Triple Duty Check Valve, Inline, 8 in, Class 125 Flange x Flange, Cast Iron MPN:0800-125TFI-B
The SSI Triple Check Valve is a reliable and durable solution for various industrial applications. Constructed from cast iron, this 8-inch flanged valve is designed for high-pressure operations, with a maximum rating of 200 PSI and a temperature limit of 212 F. The triple-duty design ensures precise control and prevents backflow, making it ideal for use in water treatment plants, chemical processing facilities, and other industries where fluid regulation is critical. With a long lead time of 40 days, this valve is suitable for applications requiring high-quality, reliable performance.
Top product features:
- Triple Duty Check Valve
- Has a 125 Class Flange Connection
- Rated For 200 PSI and a Max. Temp. of 212 F
Top product applications:
- Pressure Regulator Installation
- Steam Trap Installation
- Water Supply Line Protection
SSI triple duty check valve with an 8 in nominal size for process piping. This inline valve combines check, balancing, and shutoff functions in one unit. It features a cast iron body with flange x flange Class 125 connections and is rated for water and steam service. The disc check mechanism provides reverse-flow control. Mounting orientation: horizontal or vertical.
Key Features:
- Type: Triple duty check valve
- Size: 8 in nominal valve size with 8 in connections on both sides
- Body Material: Cast iron
- Connection Type: Flange x Flange, 125 Class Flange, ANSI Flange Class 125
- Check Mechanism: Disc
- Media: Steam, Water
- Application: Process piping
- Flow Design: Single
- full flow valve
- Flow Rate: 6,000 gpm
- Cracking Pressure: Verify manufacturer specifications before publication
- Pressure Rating: 200 psi operating pressure
- 200 psi WSP max steam pressure
- 200 psi at 250 degrees F max water pressure
- Temperature Range: 60 degrees F minimum to 300 degrees F maximum
- Seal and Seat Material: Buna-N
- Spring Material: Stainless steel
- Silent Check: Yes
- Mounting Orientation: Horizontal or vertical
- Overall Height: 18 1/2 in
- Standard: ASME B16.1
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 40 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 48.00
- Package Width: 40.00
- Package Height: 25.80
- Package Weight: 350.00
