Miniature Circuit Breaker, E FRAME Series, 80A, 2 Pole, 277/480V AC, 25kA at 120V AC MPN:EDB24080
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G6776226
Miniature Circuit Breaker, E FRAME Series, 80A, 2 Pole, 277/480V AC, 25kA at 120V AC
Protect your electrical panel with the Square D E FRAME Series Miniature Circuit Breaker, designed for reliable and efficient operation. This 80A, 2-pole breaker is rated for 277/480V AC and 25kA at 120V AC, making it ideal for use in commercial and industrial applications. With a maximum operating temperature of 104°F, this breaker can withstand harsh environments. Its compact size and bolt-on mounting style make it easy to install and integrate with Square D NF panelboards. Perfect for use in offices, schools, and other public buildings, this circuit breaker provides peace of mind and helps prevent electrical fires and damage.
Top product features:
- 80A current rating for high-power applications
- 2-pole design for separating phase control and neutral connections
- 25kA at 120V AC interrupting rating for high-voltage protection
Top product applications:
- Main Electrical Panel
- Commercial Lighting and Power Distribution
- Industrial Electrical Power Distribution
Miniature Circuit Breaker, Amps 80 A, AC Voltage Rating 277/480V AC, Circuit Breaker Type Standard, Number of Poles 2, DC Voltage Rating 125V DC, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style Bolt On, Compatible Panelboard/Load Center Series NF, Phase Single, Series EDB, Max. AIR Rating 18kA at 277/480V AC, For Use With Square D NF Panelboards, Terminal Connection Lug, Frame Size 125A/EDB, Length 5.66 in, Width 1.96 in, Depth 4.05 in, Max. Operating Temp. 104 Degrees F
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.00
- Package Width: 3.30
- Package Height: 5.00
- Package Weight: 3.50
Product info last updated on February 4, 2026 11:38am UTC
Category: Circuit Protection
