Miniature Circuit Breaker, E FRAME Series, 125A, 2 Pole, 277/480V AC, 25kA at 120V AC MPN:EDB24125
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G2993986
Miniature Circuit Breaker, E FRAME Series, 125A, 2 Pole, 277/480V AC, 25kA at 120V AC
Protect your electrical system with the Square D E FRAME Series Miniature Circuit Breaker, ideal for use in NF Panelboards. This 125A, 2-pole breaker offers reliable protection against overloads and short circuits, with a maximum interrupting rating of 25kA at 120V AC. Its compact design makes it perfect for a variety of applications, including commercial and industrial settings. The E FRAME Series breaker provides peace of mind with its easy installation and maintenance, and is compatible with Square D NF Panelboards. Ensure the safety and efficiency of your electrical system with this reliable and versatile circuit breaker.
Top product features:
- Circuit Breaker protects against overloads by interrupting the electrical circuit when excessive current is detected.
- Two-pole design allows for control of two separate circuits from a single device.
- Trip unit has a maximum interrupting rating of 25kA at 120V AC.
Top product applications:
- Industrial Control Panels
- Commercial Building Electrical Systems
- Data Center Electrical Distribution Systems
Miniature Circuit Breaker, Amps 125 A, AC Voltage Rating 277/480V AC, Circuit Breaker Type Standard, Number of Poles 2, DC Voltage Rating Not Rated, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style Bolt On, Compatible Panelboard/Load Center Series NF, Phase Single, Series EDB, Max. AIR Rating 18kA at 277/480V AC, For Use With Square D NF Panelboards, Terminal Connection Lug, Frame Size 125A/EDB, Length 5.66 in, Width 1.96 in, Depth 4.05 in, Max. Operating Temp. 104 Degrees F
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 7 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.60
- Package Width: 2.40
- Package Height: 6.20
- Package Weight: 2.18
Product info last updated on January 13, 2026 12:56pm UTC
Category: Circuit Protection
