IEC Miniature Magnetic Contactor, 1NO, 208V AC, 3 P, Non-Reversing, Screw Clamp MPN:LC1K0910L7
Free Shipping
In Stock
The Square D IEC Miniature Magnetic Contactor is a compact, reliable solution for motor control and resistive load applications. Its compact design and screw-clamp terminals make it easy to install and integrate into existing systems. With a rating for operation up to 480V AC and a high inrush current of 30VA, this contactor is suitable for a wide range of applications, including HVAC, industrial automation, and commercial lighting. Its UL Listed, CSA, and CE certifications ensure compliance with global safety standards, making it a reliable choice for use in demanding environments.
Top product features:
- The IEC Miniature Magnetic Contactor has three normally open main contacts and one normally open auxiliary contact.
- It is a three-pole, non-reversing device.
- It has screw-clamp terminals for DIN-rail mounting.
Top product applications:
- Motor control
- Resistive load applications
- Applications within specified fuse ratings as defined by IEC 60947/VDE 0660 standards
The IEC Miniature Magnetic Contactor is a compact, electrically actuated switch rated for operation within the specified voltage and current ranges per IEC standards. It is a three-pole, non-reversing device with three normally open main contacts and one normally open auxiliary contact, energized by a 208 V AC coil. Rated for use with motors and resistive loads within specified parameters. Compatible with DIN-rail mounting as per product specifications, with screw-clamp terminals.
- Coil voltage: 208 V AC
- Control circuit: AC 50/60 Hz
- Poles/Main contacts: 3P, 3 NO
- Auxiliary contact: Instantaneous 1 NO
- - Application: suitable for motor control and resistive load applications within specified fuse ratings as defined by IEC 60947/VDE 0660 standards
- - Maximum voltage rating: rated for operation up to a maximum of 480 V AC under specified conditions
- - Embedded surge suppressor: does not include an integrated surge suppression device
- compatibility with external surge protection should be verified based on application needs
- - Enclosure: designed for installation in enclosures compliant with applicable safety standards
- - Mounting: DIN Rail
- Terminals: Screw Clamp
- Series: TeSys K
- - Rated operational current: 9 A (AC-3 up to 440 V), 20 A (AC-1 up to 690 V)
- - Full load amps: capable of handling full load currents as specified when operated within the recommended parameters
- - Inrush/hold power: Inrush 30 VA
- Hold-in 4.5 VA
- - Dimensions: Width 1.73 in
- Height 1.73 in
- Depth 1.97 in
- - Certifications: UL Listed
- CSA
- CE
- UKCA
- CB Scheme
- CCC
- EAC
Additional Information
- Country of Origin: FR
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.50
- Package Width: 1.80
- Package Height: 2.50
- Package Weight: 0.25
