Miniature Circuit Breaker, E FRAME Series, 35A, 2 Pole, 277/480V AC, 25kA at 120V AC MPN:EDB24035
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G2823861
Miniature Circuit Breaker, E FRAME Series, 35A, 2 Pole, 277/480V AC, 25kA at 120V AC
Protect your electrical system with the Square D E FRAME Series Miniature Circuit Breaker, designed for use in Square D NF Panelboards. This 2-pole, 35A breaker is rated for 277/480V AC and features a toggle actuator for easy operation. With a maximum air rating of 18kA at 277/480V AC and a 25kA short-circuit rating at 120V AC, this breaker provides reliable protection against electrical overloads and faults. Ideal for commercial and industrial applications, the E FRAME Series Miniature Circuit Breaker is a reliable choice for ensuring safe and efficient electrical operation in a variety of settings.
Top product features:
- 35A circuit protection for two-pole applications
- Toggle actuator for easy manual operation
- Bolt-on mounting style for secure installation
Top product applications:
- Main electrical panel
- Industrial electrical systems
- Commercial electrical distribution systems
Miniature Circuit Breaker, Amps 35 A, AC Voltage Rating 277/480V AC, Circuit Breaker Type Standard, Number of Poles 2, DC Voltage Rating Not Rated, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style Bolt On, Compatible Panelboard/Load Center Series NF, Phase Single, Series EDB, Max. AIR Rating 18kA at 277/480V AC, For Use With Square D NF Panelboards, Terminal Connection Lug, Frame Size 125A/EDB, Length 5.66 in, Width 1.96 in, Depth 4.05 in, Max. Operating Temp. 104 Degrees F
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 7 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.30
- Package Width: 4.70
- Package Height: 4.80
- Package Weight: 2.29
Product info last updated on January 13, 2026 1:40pm UTC
Category: Circuit Protection
