Miniature Circuit Breaker, E FRAME Series, 25A, 3 Pole, 277/480V AC, 25kA at 120V AC MPN:EDB34025
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G2776103
Miniature Circuit Breaker, E FRAME Series, 25A, 3 Pole, 277/480V AC, 25kA at 120V AC
Protect your electrical systems with the Square D E FRAME Series Miniature Circuit Breaker, designed for use in NF Panelboards and compatible with EDB series load centers. This 3-pole, 25A circuit breaker is rated for 277/480V AC and 25kA at 120V AC, providing reliable protection against overloads and short circuits. Ideal for commercial and industrial applications, it offers easy installation and maintenance, with a bolt-on mounting style and toggle actuator. With a maximum operating temperature of 104°F, this circuit breaker ensures safe and efficient operation in a variety of settings, including offices, warehouses, and manufacturing facilities.
Top product features:
- Breaks circuit overload up to 25kA at 120V AC
- Has a three-pole design for phase protection
- Operates at a maximum temperature of 104 Degrees F
Top product applications:
- Industrial control panels
- Commercial electrical distribution systems
- High-voltage equipment installations
Miniature Circuit Breaker, Amps 25 A, AC Voltage Rating 277/480V AC, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating 125V DC, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style Bolt On, Compatible Panelboard/Load Center Series NF, Phase Three, Series EDB, Max. AIR Rating 18kA at 277/480V AC, For Use With Square D NF Panelboards, Terminal Connection Lug, Frame Size 125A/EDB, Length 5.66 in, Width 2.94 in, Depth 4.05 in, Max. Operating Temp. 104 Degrees F
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.40
- Package Width: 4.70
- Package Height: 3.50
- Package Weight: 3.35
Product info last updated on January 13, 2026 1:59pm UTC
Category: Circuit Protection
