Definite Purpose Magnetic Contactor, 24V AC, 3 P, Non-Reversing, 3 Phase, Box Lug & Quick Connect MPN:8910DPA63V14
Free Shipping
In Stock
The SQUARE D 8910DPA63V14 Definite Purpose Magnetic Contactor is a reliable and versatile tool for controlling power flow in heavy-duty applications. Designed for use in HVAC, data processing, and manufacturing, this device responds to electrical impulses to manage machinery operations with precision. With its non-reversing action and 24V AC coil voltage, it ensures consistent current flow direction and efficient power supply. Certified by UL and CSA, this contactor is suitable for various industrial applications, including motor controls up to 10 hp at single-phase and 30 hp at three-phase. Its compact design and easy connectivity make it an ideal choice for demanding environments.
Top product features:
- Operates on a non-reversing action, allowing for constant current flow direction.
- Responds to electrical impulses to control the flow of power in heavy-duty applications.
- Equipped with three poles for simultaneous switching of circuits in various industrial applications.
Top product applications:
- HVAC
- Data processing
- Manufacturing
The SQUARE D - 8910DPA63V14 is a Definite Purpose Magnetic Contactor, an industrial electrical device used to control the flow of power in heavy-duty applications. This tool operates by responding to electrical impulses, either allowing or interrupting power supply based on need. It's commonly utilized for managing and automating machinery operations across various sectors such as HVAC, data processing, and manufacturing.
- Action: Non-Reversing – The contactor functions with a constant current flow direction.
- Coil Voltage: Rated for operation at a coil voltage of 24V AC.
- Electrical Connection: Can be attached to an electrical circuit via box lugs or quick connect terminals.
- Frequency: Rated for operation within the frequency range of 50/60 Hz.
- Full Load Amps-Inductive & Resistive: Specified to accommodate up to maximum currents of 60 A (inductive loads) and 75 A (resistive loads).
- Horsepower Ratings: Compatible with motor controls within specified horsepower ranges based on phase and voltage
- e.g., compatible with motor controls up to an estimated range of approximately 10 hp at single-phase, 240V AC and approximately 30 hp at three-phase, 480 VAC
- Poles: Equipped with three poles that allow simultaneous switching of circuits for versatile control in various industrial applications
- Certifications: Certified by UL and CSA as meeting their standards for diverse industrial applications
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.90
- Package Width: 2.70
- Package Height: 4.30
- Package Weight: 1.50
