Molded Case Circuit Breaker, POWERPACT Q Series, 175A, 3 Pole, 240V AC, 25kA at 240V AC MPN:QDL32175
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G2170007
Molded Case Circuit Breaker, POWERPACT Q Series, 175A, 3 Pole, 240V AC, 25kA at 240V AC
The POWERPACT Q Series 175A 3-Pole Molded Case Circuit Breaker from Square D is designed for high-amperage applications, offering a high amp trip setting of 2,400A and low amp trip setting of 1,200A. Suitable for use in industrial settings, this circuit breaker provides reliable protection against electrical overloads and short circuits. Its thermal magnetic trip type ensures quick and effective response to potential issues. With a maximum air rating of 25kA at 240V AC, it can handle demanding electrical loads. Ideal for use in free-standing applications, this circuit breaker is a reliable solution for a wide range of industrial electrical needs.
Top product features:
- High Amp Trip Setting of 2,400 A
- Low Amp Trip Setting of 1,200 A
- Instantaneous Trip Fixed for Phase Protection
Top product applications:
- Industrial electrical panelboards
- Commercial building electrical distribution systems
- Heavy-duty machinery and equipment installations
Molded Case Circuit Breaker, 175 A Amps, AC Voltage Rating 240V AC, Max. AIR Rating 25kA at 240V AC, For Use With -, Series QD, High Amp Trip Setting 2,400 A, Low Amp Trip Setting 1,200 A, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating Not Rated, Terminal Connection Lug, Trip Type Thermal Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection ABC, Frame Size 250A/QD, Circuit Breaker Mounting Style Free Standing, Height 6.47 in, Width 4.5 in, Depth 3.93 in
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 52 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 8.30
- Package Width: 6.90
- Package Height: 5.50
- Package Weight: 4.70
Product info last updated on January 13, 2026 12:20pm UTC
Category: Circuit Protection
