Miniature Circuit Breaker, E FRAME Series, 25A, 2 Pole, 277/480V AC, 25kA at 120V AC MPN:EDB24025
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G1859697
Miniature Circuit Breaker, E FRAME Series, 25A, 2 Pole, 277/480V AC, 25kA at 120V AC
Protect your electrical system with the Square D E FRAME Series Miniature Circuit Breaker, designed for use with NF Panelboards. This 25A, 2-pole breaker offers reliable protection against overloads and short circuits, with a maximum interrupting capacity of 25kA at 120V AC. Its compact size and bolt-on mounting style make it easy to install and maintain. Ideal for applications such as commercial lighting, HVAC, and power distribution, this circuit breaker ensures safe and efficient operation. With a lead time of just 7 days, you can quickly get the protection you need to keep your electrical system running smoothly.
Top product features:
- 25A current rating provides adequate protection for small to medium-sized electrical circuits
- Two-pole design allows for the control of two separate circuits with a single device
- 277/480V AC voltage rating enables the breaker to handle high-voltage applications
Top product applications:
- Industrial control panels
- Commercial electrical distribution systems
- Square D NF Panelboards
Miniature Circuit Breaker, Amps 25 A, AC Voltage Rating 277/480V AC, Circuit Breaker Type Standard, Number of Poles 2, DC Voltage Rating Not Rated, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style Bolt On, Compatible Panelboard/Load Center Series NF, Phase Single, Series EDB, Max. AIR Rating 18kA at 277/480V AC, For Use With Square D NF Panelboards, Terminal Connection Lug, Frame Size 125A/EDB, Length 5.66 in, Width 1.96 in, Depth 4.05 in, Max. Operating Temp. 104 Degrees F
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 7 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.70
- Package Width: 2.50
- Package Height: 6.20
- Package Weight: 2.18
Product info last updated on February 1, 2026 7:58am UTC
Category: Circuit Protection
