IEC Miniature Magnetic Contactor, 1NO, 24V DC, 3 P, Non-Reversing, Screw Clamp MPN:LP1K1210BD
Free Shipping
In Stock
The SQUARE D IEC Miniature Magnetic Contactor is a reliable and compact solution for control panel applications. Suitable for use with motors and resistive loads, this 3-pole, non-reversing contactor features a 24V DC coil and three main normally open contacts, plus one auxiliary contact. Its compact form factor supports installation in space-constrained control panels on DIN rails or plates. Ideal for industrial applications, this contactor offers high durability and reliability, with a rated making capacity of 144A AC power circuit and 110A AC signalling circuit. Perfect for use in control panels, machines, and automation systems.
Top product features:
- It contains three main normally open contacts and one auxiliary contact as specified, suitable for use with motors and resistive loads within specified parameters.
- It has a non-reversing action, preventing the contactor from switching on when the coil is de-energized.
- It supports installation in space-constrained control panels on DIN rails or plates, allowing for compact and efficient use of space.
Top product applications:
- Motor control in industrial automation systems
- Use with resistive loads in control panels
- Control of DC motors in various applications
The SQUARE D IEC Miniature Magnetic Contactor is a TeSys K, 3-pole, non-reversing IEC contactor with a 24 V DC coil. It contains three main normally open contacts and one auxiliary contact as specified, suitable for use with motors and resistive loads within specified parameters. Its compact form supports installation in space-constrained control panels on DIN rails or plates.
- Coil voltage: 24 V DC
- - Action: Non-Reversing
- - Poles/Contacts: 3P
- main contacts 3 NO
- auxiliary contact 1 NO
- - Mounting: DIN Rail, Plate
- - Frame/Series: TeSys K
- - Maximum voltage: Power circuit up to 690 V AC
- Signalling circuit up to 690 V AC
- - Frequency: 50/60 Hz
- - Ambient operating/storage: -25 to 50 °C (operation)
- -50 to 80 °C (storage)
- - Enclosure/IP: Enclosure rating is IP2X
- no additional enclosure provided
- - Rated making capacity: 144 A (AC Power Circuit)
- 110 A (AC Signalling Circuit)
- - Full load current: Full load current ratings are based on specified conditions
- - Durability: Durability ratings are based on testing under standard conditions
- - Terminal: Screw Clamp
- - Net weight: 0.225 kg
- - Dimensions (W x H x D approx): 1.77 in x 2.28 in x 2.24 in
- - Operating speed: 3600 cycles per hour
- - Operating time: 30–40 ms (coil energisation and NO closing)
- 10 ms (coil de-energisation and NO opening)
Additional Information
- Country of Origin: FR
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.20
- Package Width: 1.60
- Package Height: 2.20
- Package Weight: 0.48
