Definite Purpose Magnetic Contactor, 480V AC, 3 P, Non-Reversing, 3 Phase, Box Lug & Quick Connect MPN:8910DPA43V06

• The SQUARE D - 8910DPA43V06 is a Definite Purpose Magnetic Contactor, an industrial electrical device designed to control the flow of power in heavy-duty applications. It operates by responding to electrical impulses, allowing or interrupting power supply based on need. This tool is commonly used for managing and automating machinery operations in various sectors like HVAC, data processing, and manufacturing.




  • Action: Non-Reversing – The contactor functions with a constant current flow direction.
  • Coil Voltage: Rated for operation within the specified voltage range of 480V AC.
  • Control Circuit Voltage: Requires specific voltage (440 V AC 50 Hz
  • 480 V AC 60 Hz) for operation.
  • Electrical Connection: Can be attached to an electrical circuit via quick connect terminals or box lugs.
  • Frequency: Designed to handle number of electrical cycles per second measured in Hertz (Hz), making it compatible with different power systems operating at a frequency of 50/60 Hz.
  • Amps-Inductive & Resistive Load Capacity: Rated to accommodate currents up to 40 A for inductive loads and up to 50 A for resistive loads. Overheating or damage may occur if these limits are exceeded.
  • Horsepower Control Capacity: Designed for use with motors of varying horsepower, based on phase and voltage levels, which can range from single-phase power supply at lower voltages (3 hp @120V) to three-phase power supply at higher voltages (20 hp @480V). The product's performance may vary depending on these factors."
