IEC Miniature Magnetic Contactor, 1NO, 24V AC, 3 P, Non-Reversing, Screw Clamp MPN:LC1K1210B7
Free Shipping
In Stock
The SQUARE D IEC Miniature Magnetic Contactor is a reliable and efficient device for switching applications in various environments. Suitable for motor control and resistive load applications, it features a 24V AC coil, 3-pole configuration, and a normally-open auxiliary contact with screw clamp terminals. This compact device offers durability with 10 million mechanical cycles and 1.3 million electrical cycles, making it ideal for use in environments requiring IP22-rated enclosures. Its DIN rail or panel mounting capability and compact size make it perfect for industrial control systems, ensuring seamless operation and efficient energy management.
Top product features:
- The device features one normally-open auxiliary contact.
- The unit is suitable for DIN rail or panel mounting.
- The contactor has a 24V AC coil.
Top product applications:
- Motor control
- Resistive load
- Inductive load
The SQUARE D IEC Miniature Magnetic Contactor is a 3-pole, non-reversing device with a 24 V AC coil. It is rated for switching applications within specified load types, and it features one normally-open auxiliary contact with screw clamp terminals. The unit is suitable for DIN rail or panel mounting as per installation guidelines and is provided without an enclosure
- compatible with environments requiring IP22-rated enclosures.
- Coil voltage: 24 V AC
- - Poles/Main contacts and aux: 3 poles
- 3 normally open main contacts
- 1 NO auxiliary contact
- - Reversing: Non-Reversing
- - Application: Motor control, resistive load
- - Maximum voltage: 690 V AC
- - Full Load Amps: 20 A (resistive), 12 A (inductive)
- - Mounting/Terminals: DIN rail or plate mounting
- Screw Clamp terminals
- - Durability: Mechanical 10 Mcycles
- Electrical 1,300,000 cycles
- - Enclosure/IP: Provided without an enclosure
- compatible with environments requiring IP22-rated enclosures
- - Physical size: 1.77 in W × 2.28 in H × 2.24 in D
- weight 0.18 kg
- - Series: TeSys K
- - Operating time: 10–20 ms
Additional Information
- Country of Origin: ID
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.10
- Package Width: 1.70
- Package Height: 2.00
- Package Weight: 0.39
