IEC Miniature Magnetic Contactor, 1NO, 240V AC, 3 P, Non-Reversing, Screw Clamp MPN:LC1K1210U7
Free Shipping
In Stock
The IEC Miniature Magnetic Contactor from Square D is a versatile and reliable device ideal for motor control and resistive load applications. Its compact IEC-style construction allows for easy mounting on DIN rails or plates, making it perfect for use in industrial settings where space is limited. With a 3-pole, non-reversing design and 1 normally open auxiliary contact, this contactor provides precise control and flexibility. Its robust construction and high electrical durability ratings ensure reliable operation, even in demanding environments, making it an excellent choice for applications in manufacturing, HVAC, and other industries where precise control is crucial.
Top product features:
- The IEC Miniature Magnetic Contactor has 3 poles for controlling 3-phase loads.
- It features a non-reversing action to prevent motor reversal.
- It includes 1 normally open auxiliary contact for additional control functionality.
Top product applications:
- Motor Control
- Resistive Load
- Non-Reversing
The IEC Miniature Magnetic Contactor is a 3-pole, non-reversing device with 1 normally open auxiliary contact (1NO) and a 240 V AC coil. It is rated for operation with motor control and resistive loads within specified parameters and uses screw clamp terminals. Its IEC-style construction is compatible with mounting on DIN rails or plates as specified.
- Series: TeSys K
- Contactor Style: IEC
- Action: Non-Reversing
- Application: Motor Control, Resistive Load
- - Coil Voltage: 240 V AC
- - Poles / Main Contacts: 3 poles
- 3 NO main contacts
- - Auxiliary Contacts: Includes 1 auxiliary contact (1NO)
- Auxiliary Form: 1NO
- - Electrical Connection: Screw Clamp Terminals
- - Enclosure: No Enclosure
- IP Rating: IP22
- - Mounting: DIN Rail, Plate
- Mounts On: Plate, Rail
- - Rated Voltage: rated for operation at voltages up to 690 V AC within the specified voltage range
- - Net Weight: 0.18 kg
- - Dimensions (Overall): 2.24 in D x 2.28 in H x 1.77 in W
- - Mechanical Durability: tested for mechanical durability up to 10 million cycles under standard conditions
- - Electrical Durability: electrical durability ratings based on standardized testing conditions
- actual performance may vary depending on application specifics
- - Hold VA: 4.5 VA
- Inrush VA: 30 VA
- - Embedded Surge Suppressor: No
- - Includes Auxiliary Contacts: Yes
- - Impedance: 3 mΩ
- - Fire Rating: complies with fire safety standards UL 94 V1 and relevant NF standards when tested according to their procedures
- - Impulse Withstand Voltage: rated to withstand impulse voltages up to specified levels under test conditions
Additional Information
- Country of Origin: ID
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.50
- Package Width: 1.90
- Package Height: 2.40
- Package Weight: 0.39
