IEC Magnetic Contactor, 1NC/1NO, 24V DC, 3 P, Reversing, Screw Clamp MPN:LC2D25BD
Free Shipping
In Stock
The SQUARE D IEC Magnetic Contactor is a versatile and reliable device for switching power circuits in various applications. Suitable for use in control panels, it conforms to relevant standards and specifications for compatibility. This compact contactor features screw clamp terminals, reversing action, and a 3-pole design with 3 normally open main contacts and 2 auxiliary contacts. Ideal for use in enclosures, it offers IP20 protection and a maximum operating temperature of 140°F. Perfect for industrial automation, manufacturing, and electrical systems, this contactor ensures efficient and safe control of power circuits.
Top product features:
- Reversing action allows the contactor to switch power circuits in both forward and reverse directions.
- 3-pole design enables the contactor to handle three-phase power circuits.
- Screw clamp terminals provide a secure and easy-to-use electrical connection.
Top product applications:
- Power Circuit Switching
- Industrial Automation
- Control Panel Compatibility
The SQUARE D IEC Magnetic Contactor is a 3-pole, 24 V DC coil, reversing-type device (1NC/1NO auxiliary) rated for switching power circuits within specified load conditions. It uses screw clamp terminals and is offered in the TeSys Deca series for DIN rail or plate mounting and is intended for use in appropriate enclosures as per installation guidelines. This compact IEC-style contactor conforms to relevant standards and specifications for control panel compatibility.
- Coil voltage: 24 V DC
- - Action: Reversing
- - Poles: 3
- - Main contacts: 3 normally open
- - Auxiliary contacts: 2 total (1NO/1NC)
- auxiliary contact form: 1NC/1NO
- - Electrical connection: Screw Clamp Terminals
- - Includes: Electrical Interlock
- protective cover
- - Embedded surge suppressor: Includes an integrated surge suppression component (if applicable)
- - Enclosure: Intended for use in appropriate enclosures as per installation guidelines
- - IP rating: IP20
- - Series: TeSys Deca
- - Standards: EN 60947-4-1, EN 60947-5-1, IEC 60947-4-1, IEC 60947-5-1, UL 508, UL Listed
- - Rated voltage: 690V AC, 300V DC
- - Maximum operating temperature: 140 Degrees F
- - Weight: 1.117 kg
- - Mechanical durability: 30 Mcycles
- - Electrical durability: 1.65 Mcycles (25 A, AC-3, <440 V)
- 1.4 Mcycles (40 A, AC-1, <440 V)
Additional Information
- Country of Origin: FR
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.60
- Package Width: 4.60
- Package Height: 5.60
- Package Weight: 2.80
