Miniature Circuit Breaker, E FRAME Series, 45A, 2 Pole, 277/480V AC, 25kA at 120V AC MPN:EDB24045
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0881097
Miniature Circuit Breaker, E FRAME Series, 45A, 2 Pole, 277/480V AC, 25kA at 120V AC
Protect your electrical systems with the Square D E FRAME Series Miniature Circuit Breaker, rated for 45A and 277/480V AC. This 2-pole circuit breaker is ideal for use in Square D NF panelboards, providing reliable protection against overloads and short circuits. Its compact design allows for easy installation and space-saving in tight electrical enclosures. With a maximum operating temperature of 104°F and a 25kA interrupting rating at 120V AC, this breaker ensures safe and efficient operation in a variety of applications, including commercial and industrial settings. Its robust design and reliable performance make it a trusted choice for electrical professionals.
Top product features:
- 45A current rating
- 2-pole design for single-phase applications
- 25kA short-circuit rating at 120V AC
Top product applications:
- Industrial Electrical Panelboards
- Commercial Electrical Panelboards
- Electrical Distribution Systems
Miniature Circuit Breaker, Amps 45 A, AC Voltage Rating 277/480V AC, Circuit Breaker Type Standard, Number of Poles 2, DC Voltage Rating Not Rated, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style Bolt On, Compatible Panelboard/Load Center Series NF, Phase Single, Series EDB, Max. AIR Rating 18kA at 277/480V AC, For Use With Square D NF Panelboards, Terminal Connection Lug, Frame Size 125A/EDB, Length 5.66 in, Width 1.96 in, Depth 4.05 in, Max. Operating Temp. 104 Degrees F
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 7 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.30
- Package Width: 4.80
- Package Height: 4.80
- Package Weight: 2.30
Product info last updated on January 15, 2026 4:54am UTC
Category: Circuit Protection
