Miniature Circuit Breaker, E FRAME Series, 90A, 2 Pole, 277/480V AC, 25kA at 120V AC MPN:EDB24090
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0869032
Miniature Circuit Breaker, E FRAME Series, 90A, 2 Pole, 277/480V AC, 25kA at 120V AC
Protect your electrical systems with the Square D E FRAME Series Miniature Circuit Breaker, designed for use with NF Panelboards. This 90A, 2-pole breaker is rated for 277/480V AC and offers 25kA at 120V AC. Its compact size (5.66 in x 1.96 in x 4.05 in) makes it ideal for tight spaces. The toggle actuator and bolt-on mounting style ensure easy installation. Suitable for single-phase applications, this breaker provides reliable protection against overloads and short circuits, ensuring the safe operation of your electrical system. Ideal for commercial and industrial use, it's a reliable choice for any electrical panelboard.
Top product features:
- Protects against overcurrent conditions with a 90A rating
- Breaks circuit in 25kA at 120V AC
- Mounts securely with a bolt-on design
Top product applications:
- Industrial electrical panelboards
- Commercial lighting systems
- High-amperage electrical distribution systems
Miniature Circuit Breaker, Amps 90 A, AC Voltage Rating 277/480V AC, Circuit Breaker Type Standard, Number of Poles 2, DC Voltage Rating Not Rated, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style Bolt On, Compatible Panelboard/Load Center Series NF, Phase Single, Series EDB, Max. AIR Rating 18kA at 277/480V AC, For Use With Square D NF Panelboards, Terminal Connection Lug, Frame Size 125A/EDB, Length 5.66 in, Width 1.96 in, Depth 4.05 in, Max. Operating Temp. 104 Degrees F
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.60
- Package Width: 2.40
- Package Height: 6.20
- Package Weight: 2.18
Product info last updated on January 15, 2026 4:52am UTC
Category: Circuit Protection
