Miniature Circuit Breaker, E FRAME Series, 20A, 1 Pole, 277V AC, 25kA at 120V AC MPN:EDB14020EPD
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0755562
Miniature Circuit Breaker, E FRAME Series, 20A, 1 Pole, 277V AC, 25kA at 120V AC
Protect your electrical system with the Square D E FRAME Series Miniature Circuit Breaker, designed for use with Square D NF panelboards. This 20A, 1-pole circuit breaker offers ground fault equipment protection and is rated for 277V AC with a maximum short circuit current of 25kA at 120V AC. Its compact size and bolt-on mounting style make it easy to install and integrate into your electrical system. Suitable for a variety of applications, including commercial and industrial settings, this circuit breaker provides reliable protection against electrical faults and overloads, helping to prevent equipment damage and ensure a safe operating environment.
Top product features:
- Ground Fault Equipment Protection
- Provides 20A of current protection
- Has a 277V AC voltage rating
Top product applications:
- Industrial Power Distribution Systems
- Commercial Electrical Panelboards
- Residential Electrical Panelboards
Miniature Circuit Breaker, Amps 20 A, AC Voltage Rating 277V AC, Circuit Breaker Type Ground Fault Equipment Protection, Number of Poles 1, DC Voltage Rating Not Rated, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style Bolt On, Compatible Panelboard/Load Center Series NF, Phase Single, Series EDB, Max. AIR Rating 18kA at 120/240V AC, For Use With Square D NF Panelboards, Terminal Connection Lug, Frame Size 125A/EDB, Length 6.64 in, Width 1.96 in, Depth 4.05 in
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 7 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.20
- Package Width: 5.50
- Package Height: 2.50
- Package Weight: 2.14
Product info last updated on February 26, 2026 11:38am UTC
Category: Circuit Protection
