IEC Miniature Magnetic Contactor, 1NO, 120V AC, 3 P, Non-Reversing, Screw Clamp MPN:LC1K1210G7
Free Shipping
In Stock
The IEC Miniature Magnetic Contactor from Square D's TeSys line is a reliable and efficient electrical switch designed to control motor and resistive loads. Its 3-pole, non-reversing action ensures consistent and safe operation, while its screw clamp terminals provide easy and secure connections. Suitable for a wide range of applications, including industrial automation and control systems, this contactor is ideal for use in environments with high electrical demands. Its compact design and durable construction make it a great choice for DIN rail or plate mounting, providing a reliable and efficient solution for electrical control needs.
Top product features:
- The product has a normally open auxiliary contact (1NO) for controlling external circuits.
- It uses a 120 V AC coil for reliable and efficient operation.
- The product is designed for DIN rail or plate mounting for flexible installation options.
Top product applications:
- Motor Control
- Resistive Load Control
- Control of Small Motors and Fans
The IEC Miniature Magnetic Contactor from the TeSys line is a 3-pole, non-reversing electrical switch intended to control motor and resistive loads. It uses a 120 V AC coil and screw clamp terminals, and includes one normally open auxiliary contact (1NO). The unit is designed for DIN rail or plate mounting and has a rated voltage of up to 690 V AC and rated current capacities as specified.
- Coil Voltage: 120 V AC
- - Action: Non-Reversing
- - Reversing: No
- - Poles: 3
- - Main Contacts: 3 Normally Open
- - Auxiliary Contacts: 1 NO (Includes an auxiliary contact configured as normally open (1NO))
- - Electrical Connection: Screw Clamp Terminals
- - Mounting Style: DIN Rail, Plate
- - Series/Frame: TeSys / TeSys K
- - Rated for operation within the specified voltage range.
- - Rated for operation at the specified current levels.
- - Frequency: 50/60 Hz
- - IP Rating: IP22
- - Enclosure: No Enclosure
- - Net Weight: 0.18 kg
- - Dimensions: Width 1.77 in, Height 2.28 in, Depth 2.24 in
- - Mechanical Durability: 10 Mcycles
- - Electrical Operating Durability: 1,300,000
- 300,000
- - Standards: BS 5424, CSA, IEC 60947, NF C 63-110, UKCA, UL Listed, VDE 0660
Additional Information
- Country of Origin: ID
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.40
- Package Width: 2.00
- Package Height: 2.70
- Package Weight: 0.39
