Power Distribution Block, Open, 4 Pole, 335 A Copper, 600 V AC/DC, Surface Mount MPN:9080LBA363104
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0571046
Power Distribution Block, Open, 4 Pole, 335 A Copper, 600 V AC/DC, Surface Mount
This Power Distribution Block from Square D is a reliable solution for efficient power distribution in a variety of applications. Suitable for use with both aluminum and copper conductors, it features four poles for line and load connections, supporting wire sizes from 6 AWG to 400 kcmil and 14 AWG to 2 AWG respectively. With a maximum current rating of 335 A and a voltage rating of 600 V AC/DC, it's ideal for commercial and industrial settings, such as data centers, hospitals, and manufacturing facilities. Its compact design and surface mount capability make it a convenient addition to any electrical infrastructure.
Top product features:
- Power Distribution Block, Open, 4 Pole, 335 A Copper, 600 V AC/DC, Surface Mount
- Supports conductor materials aluminum and copper
- Accepts line copper wire sizes from 6 AWG to 400 kcmil and load copper wire sizes from 14 AWG to 2 AWG
Top product applications:
- Main electrical panel board
- Industrial control panels
- Commercial electrical distribution systems
Power Distribution Block, For Conductor Material Aluminum, Copper, Line Connections/Pole 1, Line Side Stud Size Not Applicable, For Line Copper Wire Size - Minimum 6 AWG, For Line Copper Wire Size - Maximum 400 kcmil, Load Connections/Pole 4, Load Side Stud Size Not Applicable, For Load Copper Wire Size - Minimum 14 AWG, For Load Copper Wire Size - Maximum 2 AWG, Maximum Current - Copper Conductor 335 A, Maximum Voltage 600 V, Mounting Type Surface, Number of Poles 4, Overall Depth 2.61 in
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 1.55
Product info last updated on January 15, 2026 7:55am UTC
Category: Electrical Connectors
