IEC Magnetic Contactor, 1NC/1NO, 24V DC, 3 P, Reversing, Screw Clamp MPN:LC2D18BD

Discount: See in Cart
Free Shipping
In Stock
Brand: Square D
Part #: LC2D18BD
UPC: 785901617969
SKU
510-G0568355
Regular Price $887.59 Special Price $633.99

BBB Accredited - ResellerRatings Elite Member - SBA Service-Disabled Veteran-Owned Certified

Add to Wish List Add to Compare
IEC Magnetic Contactor, 1NC/1NO, 24V DC, 3 P, Reversing, Screw Clamp

The SQUARE D IEC Magnetic Contactor is a versatile and reliable solution for motor control and resistive load applications. Its reversing action allows for easy direction change of motor rotation, while the auxiliary contact form provides additional switching capacity. Suitable for use in systems powered by 24V DC, this contactor features screw clamp terminals for secure electrical connection. With a high operational durability rating and built-in surge suppressor, it ensures reliable performance in a range of applications, including industrial automation, HVAC, and commercial lighting. Its compact design and DIN Rail/Plate mounting compatibility make it a convenient choice for space-sensitive installations.

Top product features:

  • Reversing action: Allows the direction of motor rotation to be changed.
  • Auxiliary Contact Form: Provides additional switching capacity.
  • Built-in surge suppressor: Designed for potential voltage spikes.

Top product applications:

  • Motor control
  • Resistive load applications
  • General industrial control

The SQUARE D - IEC Magnetic Contactor is a reversing type, designed for motor control and resistive load applications. It operates within systems using a 24V DC power supply and features an auxiliary contact configuration of 1NO/1NC. The contactor has screw clamp terminals that provide an option for electrical connection, ensuring secure attachment. Its operational durability is rated for operation up to 1 Mcycles (32 A, AC-1) or up to 1.65 Mcycles (18 A, AC-3), both under less than 440 V conditions. This product comes preassembled with a reversing power busbar and includes built-in surge suppressor designed for potential voltage spikes.

Key Features:

  • - Reversing action: Allows the direction of motor rotation to be changed.
  • - Auxiliary Contact Form: Provides additional switching capacity.
  • - Coil Voltage: Operates within systems using a 24V DC power supply.
  • - Electrical Connection: Screw Clamp Terminals provide an option for electrical connection.
  • - Durability: Rated for operation up to 1 Mcycles (32 A, AC-1) or up to 1.65 Mcycles (18 A, AC-3), both under less than 440 V conditions.
  • -Surge Suppressor: Includes built-in surge suppressor designed for potential voltage spikes.
  • -Fire Rating: Meets UL94 V1 fire safety standards which indicate self-extinguishing characteristics after ignition source removal
  • -Mounting Style: Compatible with mounting on DIN Rail or Plate
  • -Rated Breaking Capacity & Making Capacity : Designed to interrupt current flow upto300A @440V and establish current flow upto140A(AC Signalling Circuit),250A(DC Signalling Circuit).
  • -Tightening Torque : Provides a torque range between 1.7 Nm(Control Circuit)and2.5Nm(Power Circuit).


    • Additional Information

    • Country of Origin: FR
    • Drop Ship Item: No
    • Blind Ship Eligible: No
    • LTL Freight Required: No
    • Lead Time: Ships in 1 days
    • Minimum Order Quantity: 1
    • Unit of Measure: EA
    • Package Length: 4.50
    • Package Width: 3.70
    • Package Height: 4.90
    • Package Weight: 2.20
    Product info last updated on January 15, 2026 7:52am UTC Category: Industrial Electrical Controls and Automation
