IEC Magnetic Contactor, 1NC/1NO, 24V AC, 3 P, Reversing, Screw Clamp MPN:LC2D32B7

• The SQUARE D IEC Magnetic Contactor is a three-pole, reversing-action device with a 24 V AC coil rated for switching power circuits within specified load conditions. It includes two auxiliary contacts (1 normally open and 1 normally closed) and uses screw clamp terminals. Part of the TeSys Deca family, it is compatible with DIN Rail or Plate mounting as per installation guidelines and is supplied without an enclosure

• suitable for use within appropriate enclosures according to applicable standards.

  - Function: Reversing-action device (no guarantee of specific operation)

• - Intended for use in motor control and resistive load applications within specified parameters
• - Poles: 3
• - Coil Voltage: 24 V AC
• - Auxiliary Contacts: 2 (1 NO / 1 NC)
• - Terminal Type: Screw Clamp
• - Series: TeSys Deca
• - Mounting: Compatible with DIN Rail or Plate mounting as per installation guidelines
• - Enclosure: Not equipped with an enclosure
• suitable for installation in protected environments conforming to IP20 ratings
• - Dimensions: Width 3.54 in
• Depth 3.62 in
• Height 3.35 in
• - Weight: 0.797 kg
• - Rated voltage levels are based on manufacturer specifications and should be operated within these limits
• - Full Load Amps: Inductive 32 A
• Resistive 50 A
• - Designed to operate at indicated current ratings under normal operating conditions
• - Rated Making Capacity: 140 A (AC Signalling)
• 250 A (DC Signalling)
• 550 A @ 440 V (Power Circuit)
• - Electrical capacity ratings are based on standard testing conditions and should be used accordingly
• - Embedded Surge Suppressor: No
• - Fire Rating: UL 94 V1
• - Environmental Attributes: Mercury Free, PVC Free, Toxic Heavy Metal Free, Pollution Degree 3
• - Operating Temperature: Max 140°F
• Min -40°F
• - Mechanical Durability: 15 Mcycles
• - Electrical Operating Durability: 1,400,000
• 1,650,000 cycles
