IEC Miniature Magnetic Contactor, 1NO, 208V AC, 3 P, Non-Reversing, Screw Clamp MPN:LC1K0610L7

• The SQUARE D IEC Miniature Magnetic Contactor is a compact, three-pole, non-reversing electrical switch intended for IEC-based control circuits. Features a 208 V AC coil, one auxiliary contact (1NO), and three main normally open contacts (3 NO). Uses screw clamp terminals. Suitable for use in space-constrained control panels, it supports DIN Rail or plate mounting and is rated for operation within the specified voltage range of up to 690 V AC at 50/60 Hz frequency.

  Key features

• - Poles: 3
• - Main contacts: 3 NO
• - Auxiliary contact: 1 NO (Instantaneous)
• - Coil voltage: 208 V AC
• - Action: Non-Reversing
• - Electrical connection: Screw Clamp Terminals
• - Mounting style: DIN Rail, Plate
• - Enclosure: No Enclosure
• - IP rating: IP22
• IP2X (VDE 0106)
• - Rated insulation voltage: 600/690 V
• - Maximum voltage rating: 690 V AC
• - Rated making capacity: 110 A
• - Frequency: 50/60 Hz
• - Net weight: 0.18 kg
• - Dimensions (overall): Width 1.77 in
• Depth 2.24 in
• Overall Height 2.28 in
• - Series: TeSys K
• - Maximum operating rate: 3600 cyc/h
• - Mechanical durability: 10 Mcycles
• - Hold-in power: 4.5 VA
• - Inrush VA: 30 VA
• - Control circuit voltage: 200 to 208 V AC 50/60 Hz
• - Reversing: No
• - Certifications: CB Scheme
• CCC
• CE
• CSA
• EAC
• UL
• UKCA
