Swivel Assembly, 3/8 MPN:TT2CUA11G
Free Shipping
In Stock
The Speedaire TT2CUA11G 90-degree swivel assembly is a versatile component designed for pneumatic systems, providing rotational movement between connected components. Constructed from steel with an oxidized finish, it includes nitrile seals for sealing performance and operates within a pressure range of 0-300 psi and temperature range of -4-140°F. Suitable for use with Speedaire brand 2CUA1 series reels, model L805102, this swivel assembly is ideal for applications requiring directional flow, such as in pneumatic conveying systems, material handling, and automation. Its compact design and durable construction make it a reliable choice for various industrial applications.
Top product features:
- The product provides a 90-degree swivel for rotational movement between connected components.
- It includes nitrile seals for maintaining sealing between connected ports.
- The product is designed for pneumatic systems with an operating pressure range of 0 psi to 300 psi.
Top product applications:
- Pneumatic system components
- Pneumatic tool and equipment supply lines
- Compressed air distribution systems
The SPEEDAIRE - TT2CUA11G is a 90-degree swivel designed for pneumatic systems. It includes nitrile seals for sealing between the inlet and outlet ports. It fits the Speedaire brand and is compatible with the 2CUA1 reel series and model number L805102. This swivel provides rotational movement between connected components. It is constructed from steel with an oxidized finish and includes nitrile seals to maintain sealing between connected ports. The inlet and outlet ports feature female NPT threads, with the inlet sized at 3/8 inch FNPT and the outlet at 1/4 inch FNPT.
Key Features:
- - Angle: 90 degrees bend between connection faces for specific directional flow.
- - Material: Steel construction with oxidized coating for surface treatment.
- - Inlet: Female 3/8 in NPT thread with 3/8 in FNPT swivel connection.
- - Outlet: Female 1/4 in NPT thread with 1/4 in FNPT swivel connection.
- - Seals: Includes nitrile seal material for sealing performance.
- - Operating Pressure Range: 0 psi minimum up to a maximum of 300 psi.
- - Operating Temperature Range: From -4 Degrees F up to 140 Degrees F.
- - Rated for compatibility with Speedaire brand 2CUA1 series reels, model L805102.
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.00
- Package Width: 2.00
- Package Height: 1.50
- Package Weight: 0.11
