Push-Fit Adapter Fitting, Push-to-Connect x MUNF, 5/32 in Tube OD, 10-32 Pipe Size, Plastic MPN:KQ2S03-32A
The SMC KQ2S03-32A push-on hose fitting is a reliable and efficient solution for connecting and securing hose ends in industrial and commercial fluid applications. Its stainless steel construction ensures durability and corrosion resistance, while its 10-32 thread size and 0-150 psi operating pressure range make it compatible with a variety of systems. Suitable for use with nylon, soft nylon, and polyurethane tubing, this fitting is ideal for applications such as pneumatic systems, hydraulic systems, and fluid transfer. Its leak-proof seal and wide operating temperature range (23-140°F) make it a valuable addition to any fluid handling system.
Top product features:
- Push-on hose fitting creates a leak-proof seal when connecting hose ends.
- The fitting is constructed from stainless steel, known for its durability and corrosion resistance.
- The fitting is rated for operation within a pressure range of 0 150 psi.
Top product applications:
- Industrial fluid applications
- Pneumatic systems
- Automated manufacturing
The SMC - KQ2S03-32A is a type of push-on hose fitting primarily used in a variety of industrial and commercial fluid applications. As a key component of a pneumatic system, this tool's main function is to connect and efficiently secure hose ends to create a leak-proof seal. This particular model is recognized for its effectiveness in systems operating at a wide range of pressures and temperatures.
Key Features:
- Part number: KQ2S03-32A – This is the manufacturer's unique code used to identify this particular type of push-on hose fitting.
- Material: Stainless Steel – The fitting is constructed from stainless steel, known for its durability and corrosion resistance.
- Connection Thread: 10-32 - This numerical designation details the specific size of the thread, indicating compatibility with hoses or pipes of matching thread size.
- Operating Pressure Range: 0 - 150 psi - The fitting is rated for operation within this pressure range.
- Operating temperature range: 23 to 140 degrees Fahrenheit - The fitting is rated for operation within the specified temperature range.
- Tubing OD: 3mm - This indicates the outer diameter of the hose or tubing that the fitting can accommodate.
- Thread Standard: National Fine - This indicates that the fitting's thread pattern conforms to a national standard for fine-threaded fasteners.
- Applicable Tubing Material: Nylon, Soft Nylon, Polyurethane - The fitting is compatible with the specified tubing materials: Nylon, Soft Nylon, Polyurethane.
Additional Information
- Country of Origin: SG
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 0.80
- Package Width: 0.50
- Package Height: 0.50
- Package Weight: 0.01
