Vacuum Ejector, Single, 1/8 In NPT MPN:ZM071HT-K5LZ
Vacuum Ejector, Single, 1/8 In NPT
The SMC Vacuum Ejector is a versatile and reliable component ideal for various industrial applications, including pneumatic systems, robotics, and automation. Its compact design and high flow rate make it suitable for applications requiring precise control and efficient operation. The ejector's ability to handle high vacuum pressures and temperatures up to 60°C makes it suitable for use in a range of environments. Its ease of integration and maintenance also make it a valuable addition to any system, providing a reliable and consistent flow of air and gases. Its applications include manufacturing, packaging, and material handling.
Top product features:
- Includes Muffler
- Needle Flow Control Valve
- Release Valve
Top product applications:
- Vacuum ejectors are often used in pneumatic conveying systems to move dry bulk materials such as powders and granules.
- Vacuum ejectors can be used in laboratory settings to create a vacuum environment for experiments and testing.
- Vacuum ejectors can be used in medical devices to create a vacuum for applications such as blood sampling and medical suction.
Item Vacuum Ejector, Includes Muffler, Needle Flow Control Valve, Release Valve, Supply Valve, Maximum Flow Rate 24 lpm, Maximum Operating Temperature 60 Degrees C, Maximum Supply Pressure 72 psi, Overall Length 98 mm, Overall Width 15.5 mm, Pressure Port Size 1/8 in, Pressure Port Type NPT, Vacuum Port Size 1/8 in, Vacuum Port Type NPT, Vacuum Pressure @ 40 PSI -55 kPa, Vacuum Pressure @ 75 PSI -84 kPa, Valve Supply Voltage 24 V DC, Valve Type 2 NC Supply and Release, Weight 250 g
Additional Information
- Country of Origin: JP
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.40
- Package Width: 5.30
- Package Height: 1.20
- Package Weight: 0.45
Product info last updated on February 23, 2026 11:08pm UTC
Category: Compressors, Air Tanks and Pneumatic Parts
